Fully Automatic Insulation Boots Withstand Voltage Test Device
Details
METX‑W6D2 Fully Automatic Insulation Boots Test System, following national grid standards, is an 8-channel automatic testing equipment. It features wireless anti-interference transmission, 7-inch touch screen and full-process automatic operation, ideal for large-scale batch testing in power generation enterprises, high-voltage equipment factories and professional testing institutions.
Category
Electric Safety Tools Test Equipment
Share to
Description

Fully Automatic Insulation Boots Withstand Voltage Test Device



Product Introduction



    METX‑W6D2 Fully Automatic Insulation Boots & Gloves Withstand Voltage Test System is developed strictly following State Grid "Electrical Safety Work Procedures" and the "Preventive Test Procedures for Electrical Safety Tools". All technical indicators fully meet national standards, realizing full-automatic withstand voltage inspection for insulation protective appliances. It is designed for large-scale, high-efficiency batch testing scenarios, widely used in core fields that require standardized and batch testing.



Product Parameter (specification)



(1) Power Supply Input Voltage

220V±10% 50Hz

(2) Control Box Output Voltage

0-250V

(3) Control Box Output Current

25A

(4) Rated Output Voltage

100KV

(5) Rated Output Capacity

5KVA

(6) Maximum Range

25mA

(7) Leakage Current Range with Trip System

≥12mA

(8) Voltage Measurement Error

±1% +3 digits

(9) Leakage Current Measurement Error

±1% +3 digits

(10) Leakage Current Resolution

0.01mA

(11) Digital Timer

99 minutes freely adjustable

(12) Ambient Temperature

-10°C to 40°C

(13) Humidity

≤90% RH, no condensation, no instrument flickering

(14) Control Box Dimensions

420mm × 340mm × 520mm

(15) Tester Dimensions

260mm × 980mm × 480mm

(16) Control Box Weight (kg)

22

(17) Tester Weight (kg)

8



Product feature and application



  1. 8-channel simultaneous automatic test: Support testing 8 pairs of insulation boots or gloves in one batch. Each channel works independently with separate tripping protection; single channel fault will not interrupt the whole test process, greatly improving batch testing efficiency.
  2. Dry steel bead testing mode: Internal steel bead dry test replaces traditional water injection, no need for long-time drying after inspection, suitable for large-batch continuous testing and improving work efficiency.
  3. Wireless anti-interference transmission: High and low voltage isolated design, leakage current data transmitted wirelessly, greatly improving operator safety level, suitable for large-scale test sites with high safety requirements.
  4. 7-inch touch color screen: Real-time display of test voltage, 8-channel leakage current, timing and system calendar with Chinese & English prompt, intuitive data and simple operation, suitable for professional operators to conduct standardized testing.
  5. Full-process automatic operation: Equipped with DC motor voltage regulation, automatic switch closing, standard speed voltage rising, voltage holding timing and automatic voltage drop & reset; test data can be saved automatically, reducing manual operation and ensuring test standardization.
  6. Professional matching fixture: Special grounding tray for insulation boots and dedicated test vessel for gloves, perfect for mass rapid detection, meeting the needs of large enterprises and testing institutions for batch compliance testing.



Prodection details



  • Large power generation enterprises (thermal power, hydropower, nuclear power, wind power) for batch preventive testing of insulation protective equipment
  • High-voltage equipment manufacturing plants for factory inspection of insulation boots and gloves
  • Professional testing institutions and metrology institutes for standardized compliance testing
  • Large industrial and mining enterprises with high demand for batch testing of insulation protective tools
  • Education and training organizations for teaching and practical operation of insulation equipment testing
  • Emergency rescue departments for rapid batch inspection of insulation protective equipment



Company Qualifications





FAQ

1)Can the device automatically save test data for batch testing?

Yes. The device supports full-process automatic operation, and after the test is completed, it can automatically save the test data of each channel, which is convenient for large enterprises and testing institutions to sort out and archive test reports uniformly.

2)How to ensure the stability of wireless transmission during large-scale batch testing?

The device adopts anti-interference wireless transmission technology, which can effectively avoid signal interference in large-scale test sites, ensure the accuracy of leakage current data transmission, and ensure the smooth progress of batch testing.

3)Can the test time be adjusted according to different batch testing needs?

Yes. The device is equipped with a digital timer with an adjustable range of 0–99 minutes, which can be flexibly set according to the batch size and test requirements, adapting to the standardized testing needs of different scenarios.
