MOEORW-WNYC1 Programmable Voltage Tester

The MOEORW-WNYC series programmable withstand voltage tester is a high-performance electrical strength testing instrument, suitable for rapid testing on production lines and high-precision testing in laboratories. It is widely used for insulation withstand voltage testing of various electrical products.

Equipped with a 32-bit ARM chip, it offers precise high-voltage output, supports multiple parameter settings, data storage, and various additional functions, and features abundant communication interfaces, making it easy to operate and providing comprehensive safety protection.

Product Introduction

The MOEORW-WNYC series programmable withstand voltage tester is a high-performance instrument specifically designed for testing electrical strength. It allows for software-configurable settings such as output voltage, leakage current alarm value, and test time, and features a variety of automatic testing functions.

This series of testers has high high-voltage output accuracy (better than 2%) and can be configured with RS-232/485 computer interface and remote control interface. It is suitable for both rapid flow testing on production lines and multi-functional high-precision requirements in laboratories.

The instrument can perform electrical strength tests on appliances with basic insulation, supplementary insulation, and reinforced insulation. It is suitable for electrical strength testing of household appliances, instruments, office equipment, power tools, and insulating materials.

Product Parameter (specification)

3.1 Overall Specifications

model	10 / -20 / -40	5kV 100mA	5kV 200mA
working power supply	AC 220V±10%, 50Hz±5%	AC 220V±10%, 50Hz±5%	AC 220V±10%, 50Hz±5%
Total no-load power consumption	≤20W	≤20W	≤20W
Usage Environment	Temperature 20±10℃; Relative humidity ≤75% RH	Temperature 20±10℃; Relative humidity ≤75% RH	Temperature 20±10℃; Relative humidity ≤75% RH
External dimensions	305 * 380 * 1 16 mm (Width * Depth * Height)	30 1* 42 0* 1 33 mm (Width * Depth * Height)	345 * 500 * 200mm (Width * Depth * Height)
weight	≤10kg	≤1 6 kg	≤ 30 kg

3.2 Technical Parameters

model		5kV 10mA	5kV 20mA	5kV 40mA	5kV 100mA	5kV 200mA
Output voltage range		AC 100 ~ 5000 V
Output voltage	Voltage rise time setting	0.1~999.9s (0 = off)
	Voltage droop time setting	0.1~999.9s (0 = off)
	Output voltage regulation	±(2% of set value + 5V)
	Output voltage resolution	1V
	Output voltage accuracy	± (2% read the numerical value + 3 words)
	Output waveform and frequency	Sine wave (crest factor 1.3–1.5), selectable from 45 Hz to 100 Hz, step size 1 Hz.
Breakdown current	Breakdown current limit Set range	0.001mA ~ 1 0.00mA	0.001mA ~ 2 0.00mA	0.001mA ~40.00mA	0.001mA ~ 100.0 mA	0.0 80 mA ~ 200.0 mA
	Breakdown current lower limit Set range	0.001mA～ 1 0.00mA (0 = Off)	0.001mA～ 2 0.00mA (0 = Off)	0.001mA～40.00mA (0 = Off)	0.001mA ～ 100.0mA (0 = Off)	0.0 80 mA ~ 200.0 mA (0 = Off)
	Breakdown current measurement range	0.010 mA ～ 1 0.00 mA	0.010 mA ～ 2 0.00 mA	0.020 mA ～40.00 mA	0.050 mA ～ 100.0 mA	0.080 mA ～ 200.0 mA
	Breakdown current measurement resolution	0.001mA/0.01mA ( < 9.999mA ) 10.00mA)	0.001mA/0.01mA ( < 9.999mA ) 10.00mA)	0.001mA/0.01mA ( < 9.999mA ) 10.00mA)	0.001mA/0.01mA( < 9.999mA /> 10.00mA)	0.001mA/0.01mA ( < 9.999mA ) 10.00mA)
	Breakdown current measurement accuracy	± (2% read the numerical value + 3 words)
	Current clearing	0.000-9.999mA

Product feature and application

( 1 ) The adoption of a mainstream 32-bit ARM control chip to replace the original 8/16-bit microcontroller greatly improves control capabilities and provides users with more powerful control functions and user-friendly interaction.

(2) The modular, multi-tasking real-time operating software provides faster computing power, more flexible and diverse control, and better drives the hardware to achieve greater efficiency.

(3) It adopts LED digital tubes and combination buttons to provide users with a multi-functional and user-friendly operation method.

(4) The modular hardware board design and standardized board interfaces enable better quality control and improved product maintainability, thereby enhancing the overall quality of the product.

(5) The use of a high-power output power supply further enhances the output load capacity.

(6) Users can set multiple sets of data and save the user data.

(7) While retaining the original functions of the old safety regulation form, functions such as slow rise and fall, communication, and switch quantity can be added .

Prodection details

It is suitable for electrical strength testing of household appliances, instruments, and office equipment, and can also be used for withstand voltage testing of power tools and insulating materials, meeting both production line testing and high-precision laboratory testing needs.
