MOEORW-W2300A AC Hipot safety testing 5kV
Product Introduction
This single AC hipot tester is dedicated to AC-only dielectric strength and insulation withstand testing. Adopting pure sine wave AC output design, the equipment delivers stable high voltage, effectively detecting insulation defects, leakage risks and electrical breakdown of finished products. Compact and easy to operate, it is widely used in batch quality control and routine safety verification.
Product Parameter (specification)
2.1 Output voltage, basic error, leakage current, preset alarm current and tolerance are shown in Table 1.
|
capacity |
kVA |
1 |
|
Output voltage |
AC (kV) |
5 |
|
Basic error |
± (5%r + 3d) |
|
|
Leakage current |
mA |
0 -200 |
|
Allowance |
± (5%r + 3d) |
|
|
Alarm current |
mA |
0.5-200 |
|
Allowance |
± (5%r + 3d) |
|
|
Note 1: r - reading, d - number of digits Note 2: Basic error and tolerance conditions: ambient temperature 23℃±5℃, relative humidity not exceeding 80%. |
||
2.2 Test time, dimensions and weight are shown in Table 2 .
|
Capacity kVA |
Test time s |
External dimensions 1×b×h, mm: |
weight (kg) |
|
1 |
1~99 |
440×390×235 |
17 |
- 2.3 Usage Conditions
Temperature 0℃～40℃
Relative humidity not exceeding 80%
There are no strong electromagnetic interference sources in the vicinity, no large amounts of dust or corrosive gases, and the ventilation is good.
- 2.4 Power supply：AC 220V, tolerance ±10%, 50Hz .
Product feature and application
- Pure AC high voltage output, fully adapted to conventional electrical safety regulations
- High-precision current monitoring, real-time overload and breakdown alarm
- Steady voltage regulation, avoiding voltage fluctuation during long-time testing
- Humanized operation panel, suitable for workshop continuous use
Prodection details
Suitable for household appliances, small electrical components, wiring harnesses and daily electronic products. Mainly used for factory batch inspection, production line safety screening and regular product performance check.
Company Qualifications
1)What products is this 5kV AC hipot tester suitable for?
It is mainly for household appliances, internal wiring, wire harnesses and common consumer electronics. Perfect for daily factory batch inspection and routine insulation screening.
2)Does the machine support continuous long-time testing?
Yes. With optimized circuit design and stable voltage supply, it can sustain repeated aging tests and mass production line non-stop detection.
3)What safety protection functions does it have?
Equipped with high-voltage short-circuit protection, breakdown automatic trip and audible & visual alarm, ensuring operator safety and device stability
