Product Overview
The MOEORW-W160 is a professional handheld infrared thermal imager equipped with a 192×144 pixel uncooled infrared detector, delivering high-definition thermal imagery and precise temperature measurement results. It integrates an 8-megapixel visible light camera, supporting editable multi-mode temperature measurement rules including point, line and box detection, as well as segmented adjustable emissivity parameters. Matched with dedicated mobile APP and desktop analysis software, this device provides standardized infrared thermal inspection solutions for engineering practitioners in various industrial sectors.
Product Technical Parameters
Thermal Imaging Module
|
Parameter Item |
Specification |
|
Detector Type |
Uncooled Infrared Detector |
|
Response Wavelength Band |
7.5~14 μm |
|
Noise Equivalent Temperature Difference (NETD) |
＜50 mk (@25℃, F#=1.0) |
|
Thermal Image Resolution |
192 × 144 |
|
Lens Focal Length |
6.9 mm |
|
Field of View (FOV) |
18.75° × 14.1° |
|
Digital Zoom Range |
Continuous 1.0–8.0× |
|
Frame Rate |
25 Hz |
|
F-number |
F1.0 |
|
Temperature Measurement Range |
-20℃ ~ 150℃; 100℃ ~ 550℃ |
|
Temperature Measurement Accuracy |
±2℃ or ±2% of reading, whichever is larger |
|
Instantaneous Field of View (IFOV) |
1.74 mrad |
Visible Light Camera Module
|
Parameter Item |
Specification |
|
Still Image Resolution |
3264 × 2448 |
|
Video Recording Resolution |
1600 × 1200 |
Display & Image Output
|
Parameter Item |
Specification |
|
Display Screen |
3.5-inch 640×480 LCD Capacitive Touch Screen, Sunlight-readable |
|
Pseudocolor Modes |
8 modes: White Heat, Black Heat, Blue-Red, Rainbow, Iron Red, Red Heat, Fusion, Rain |
|
Display Composite Modes |
Thermal Image, Visible Light, Image Fusion, Picture-in-Picture, Mixed Display |
System & Hardware Configuration
|
Parameter Item |
Specification |
|
Alarm Function |
Audible & Visual Linked Alarm |
|
Wireless Connection |
Bluetooth, Wi-Fi |
|
Auxiliary Functions |
Laser Pointer, Built-in Fill Light, Text Annotation, 60s Voice Annotation |
|
Storage Capacity |
Built-in 16G storage, expandable up to 128G via SD card |
|
External Interface |
TYPE-C Port |
|
Power Supply |
Rechargeable Lithium-ion Battery, replaceable on-site |
|
Continuous Working Time |
Up to 6 hours |
|
Operating Environment |
Ambient Temperature: -10℃ ~ 50℃; Humidity ≤95% RH |
|
Protection Grade |
IP54 Dustproof & Waterproof |
|
Drop Resistance |
2-meter free fall protection |
|
Net Weight |
660 g |
|
Overall Dimension |
244 mm × 100 mm × 104 mm |
|
EMC Compliance Standard |
GB/T17799.2, GB 17799.3-2012 |
Product Features
Hardware & Structural Design
1.Manual focusing lens structure, supporting continuous 1–8× digital zoom for flexible distant and close-range inspection.
2.3.5-inch sunlight-compatible capacitive touch screen, enabling direct on-screen parameter adjustment without physical button operation.
3.Replaceable lithium battery design, supporting hot swap on-site to eliminate power outage interruption during long-duration field inspections.
4.IP54 environmental protection and 2m anti-drop structure, adapting to complex outdoor and industrial workshop operating conditions.
Temperature Measurement Performance
1.Multi-region temperature measurement algorithm covering point, line and rectangular box detection, with independent emissivity value configurable for each detection area.
2.Dual-segment temperature measuring range covering low-temperature cold objects (-20℃) to high-temperature industrial equipment (550℃), with dual standard accuracy calibration to guarantee measurement reliability.
3.All captured thermal images store complete full-screen temperature data, supporting offline secondary temperature analysis after importing files to supporting PC client software.
Data Acquisition & Transmission Function
1.Integrated 8MP visible light camera, supporting simultaneous capture/recording of thermal, visible, fused and picture-in-picture composite images/videos.
2.Built-in laser indicator and auxiliary fill light to mark target measurement positions clearly in dim environments.
3.Support text annotation and up to 60-second voice recording for on-site defect marking without extra recording tools.
4.Dual Bluetooth & Wi-Fi wireless transmission modules, enabling real-time data synchronization with dedicated mobile APP for remote viewing and file export.
Post-processing Compatibility
1.Multiple industry-standard pseudocolor and composite display modes to adapt to different fault identification scenarios.
2.TYPE-C universal data interface for fast file transfer and battery charging; expandable storage up to 128G for massive on-site data recording.
Product Application Scope
This thermal imager is applicable to multiple industrial and inspection sectors:
- Higher Education & Scientific Research: Laboratory thermal distribution testing, material thermal characteristic research
- Power Industry: Power equipment patrol inspection, transformer, cable and cabinet overheating fault detection
- Petroleum & Petrochemical: Pipeline temperature monitoring, equipment heat loss inspection
- Coal & Metallurgy: High-temperature furnace equipment monitoring, metal processing thermal defect detection
- Construction Industry: Building wall heat loss detection, thermal bridge inspection, waterproof layer hidden trouble checking
- Property Facility Inspection: Central air conditioning, electrical pipeline and public facility routine maintenance
- Insurance Survey: Fire residual temperature analysis, equipment damage thermal evidence collection
- Rail Transit: Train electrical component, track circuit overheating inspection
- General & Large Machinery Manufacturing: Mechanical friction part temperature monitoring
- High-tech, Laser & Die-casting Industries: Precision equipment thermal balance detection
Standard Accessories List
Complete standard delivery package includes the following components:
1.Main thermal imager host ×1 (pre-installed 1 lithium battery, 1 SD memory card and hand lanyard)
2.Spare lithium-ion battery ×1
3.Charging base ×1
4.Power adapter ×1
5.TYPE-C USB data cable ×1
6.User operation manual ×1
7.High-strength impact-resistant carrying case ×1
FAQ
Q1: What is the continuous working time of the MOEORW-W160 thermal imager?
A1: Single full-charged battery supports 6 hours of continuous operation; spare batteries allow instant replacement for non-stop field work.
Q2: Can the device measure temperature objects above 550℃?
A2: The fixed temperature measurement upper limit is 550℃. Measuring objects exceeding this range will cause inaccurate readings and may damage the detector.
Q3: Is it possible to analyze stored thermal images without connecting to a computer?
A3: On-device basic temperature data viewing is available, while professional offline data analysis and report generation require supporting PC client software.
Q4: Does the equipment support long-distance wireless real-time image transmission?
A4: Wi-Fi and Bluetooth modules are built-in to connect with the matching mobile APP for real-time image transmission within short-range wireless coverage.
Q5: What storage expansion capacity does the thermal imager support?
A5: The device comes with a 16G SD card by default, and can be expanded to a maximum of 128G SD card for image and video storage.
Q6: Can the unit work normally under rainy outdoor environments?
A6: It carries IP54 protection grade, which can resist splashing water but cannot be immersed in water or exposed to heavy rain for a long time.
