High-Precision Industrial Acoustic Imager

MOEORW-WAS88 is the standard acoustic imaging model without built-in infrared thermal detection hardware, adopting a 144-element MEMS microphone array to reconstruct spatial sound field distribution through ultrasonic and audible sound signal collection. It supports real-time tracking of sound sources on static and moving objects within the 2kHz–130kHz frequency band. Equipped with laser distance measurement, auxiliary fill light, multi-stage digital zoom and industrial fault analysis algorithms, the device focuses on acoustic anomaly detection scenarios where thermal temperature measurement is unnecessary. All captured audio, image and video data can be stored locally, analyzed on the device or exported as compressed packages for secondary offline analysis on external computers.

Acoustic Imaging Core Index

Visible Camera & Storage Configuration

Hardware & System Configuration

1. Streamlined Acoustic-only Hardware Layout Removed infrared thermal imaging assembly to optimize overall weight for long-duration handheld patrol tasks. Independent physical control keys for snapshot trigger, laser ranging and auxiliary fill light realize one-handed operation in field environments. Detachable lithium battery supports two charging methods: direct charging via device Type-C port or separate charging dock charging.
2. High-density Microphone Array Delivers Stable Ultrasonic Imaging 144 independent MEMS microphones eliminate ghost image interference during sound field rendering, with ultra-wide frequency coverage adapting to low-frequency mechanical noise and high-frequency ultrasonic leakage signals. Configurable central focus area function suppresses surrounding environmental noise to enhance detection sensitivity for faint leakage signals.
3. Three Independent Industrial Measurement Algorithm Modes Built-in three mutually switchable working modes with targeted analytical logic: Partial Discharge Mode generates real-time PRPD phase diagrams and automatically classifies insulation discharge defects; Gas Leak Mode calculates real-time leakage flow and annual economic loss values for air pipelines; Mechanical Abnormal Sound Mode outputs vibration fault characteristic indicators for rotating machinery health evaluation.
4. Complete Local Recording & On-board Analysis Pipeline Support instant photo and video capture, multi-dimensional file annotation (text, voice, image and tag markers). On-device spectrum and time-frequency spectrum analysis available, enabling PDF inspection report generation without external computer support. Files can be transmitted via Bluetooth, Wi-Fi, USB wired link or uploaded to cloud server for remote storage.
5. Diversified System Tuning & Remote Maintenance Functions Freely switch sound field display logic between sound source marker mode and continuous cloud map mode, with adjustable color palette and dynamic display range. Built-in electronic compass, Bluetooth real-time audio monitoring, auto screen dimming and custom sleep timing functions; support OTA online firmware upgrade and local update via FTP or USB storage media.
6. Flexible File Management & Offline Data Export Function Independent built-in album management system, supporting custom album creation, file screening, multi-file batch selection and batch export. Original detection data can be exported as compressed packages compatible with offline PC analysis software for secondary post-processing in office scenarios.

1.Power Station & Grid Patrol: Partial discharge detection for high-voltage cabinets, transformers, insulating sleeves and cable joints; distinguish corona, surface and floating discharge faults through PRPD spectral characteristics.
2.Factory Pneumatic Pipeline Inspection: Leak detection for compressed air pipelines, valves, flanges and pressure vessels; calculate real-time gas loss and annual operational waste volume.
3.Rotating Machinery Condition Monitoring: Abnormal noise screening for motors, fans, bearings and gear pumps; judge early component wear failures via kurtosis, crest factor and spectrum fluctuation metrics.
4.Production Workshop Noise Source Localization: Locate abnormal noise points of production equipment, air supply and exhaust pipelines, hydraulic systems; track transient impact sound sources during production operation.
5.Energy Storage & Auxiliary Equipment Routine Inspection: Acoustic anomaly screening for ventilation systems, cooling devices and pressure pipelines where thermal temperature measurement functions are not required.
