Qualitative Gas Leak Detector

The MOEORW-WQL13qualitative gas leak detector is a portable, battery-powered leak inspection device integrated with a microcontroller featuring advanced digital signal processing. Equipped with a built-in mechanical suction pump at the sensing port, the unit generates stable air intake flow to realize real-time gas leakage sampling. It supports one-handed operation with ergonomic keypad layout, multi-level adjustable sensitivity, tri-color LED visual alarm and audible alert system. The device delivers instant response and rapid zero reset after detecting heavy leaks, designed for continuous on-site gas leak screening of SF6 gas.

Hardware & Structural Design
1.Embedded microcontroller with advanced digital signal processing module for precise signal analysis.
2.Tri-color LED visual leakage indicator with graded leakage grid display and matched audible alarm signal.
3.7-level adjustable sensitivity module via dedicated up/down sensitivity keys on the ergonomic handheld keypad.
4.Built-in mechanical suction pump at sensing port to generate physical sampling airflow for consistent gas intake.
5.Independent battery test function and real-time battery voltage display for power status monitoring.
6.Ergonomic one-hand operation structure with flexible soft probe and protective sleeve for sensor nozzle.
7.Wireless portable design powered by replaceable alkaline batteries without external power wiring.


Performance Indicators & Practical Application Values
1.Near-zero response time ensures rapid on-site leakage identification.
2.1-second fast zero reset enables continuous detection right after exposure to high-concentration leak points.
3.Short 2-second warm-up period minimizes standby waiting time before inspection.
4.Unlimited continuous working mode supports long-duration field batch testing tasks.
5.Mute function available to suppress audible alerts for noise-sensitive working environments.
6.Independent RESET key supports manual zero calibration for unstable background gas interference.

1.PVC storage transport case
2.Two pieces of 1.5V C-type alkaline batteries
3.Spare sensor port assembly

Main Components
1.Sensor nozzle
2.Sensor nozzle protective sleeve
3.Power ON/OFF button
4.Battery test button
5.Activation start key
6.Mute key
7.Sensitivity increase key
8.Sensitivity decrease key
9.LED leakage indicator screen
10.Flexible soft detection probe


Working Principle
The internal mechanical suction pump draws ambient gas through the sensor nozzle and flexible probe into the sensing unit. The microcontroller processes gas concentration signals via digital signal processing algorithms. Concentration data is converted into graded visual tri-color LED prompts and synchronized audible alarms. Operators can adjust detection sensitivity via dedicated keys; the system automatically resets baseline within 1 second after high-concentration gas detection to avoid signal lag. Built-in battery monitoring module detects remaining voltage and displays real-time power status via dedicated test function.
