MOEORW-WPD-S4D Partial Discharge Testing System

The MOEORW-WPD-S4D Partial Discharge Testing System comes standard with 4 channels, expandable to 16 channels, has a detection sensitivity of <0.1pC, an 80MHz sampling rate, and 14-bit sampling accuracy. It complies with IEC60270 and GB/T7354-2018 standards and is suitable for testing various types of high-voltage equipment.

The device supports 10kHz-1MHz filter adjustment, 60dB adjustable gain, measurable capacitance of 6pF~250μF, wide operating temperature range of -10℃~50℃, and achieves accurate partial discharge measurement and intelligent analysis through hardware and software collaboration.

Product Introduction

The MOEORW-WPD-S4D multi-channel partial discharge (PD) test set features a compact design and can be remotely controlled via a PC or laptop through a TCP/IP network. This instrument is suitable for type testing, factory testing, and acceptance testing of high-voltage products, and can perform quantitative testing of partial discharge in motors, transformers, cables, bushings, capacitors, transformers, surge arresters, switches, and other high-voltage electrical appliances. The digital partial discharge detector meets IEC60270 and GB/T7354-2018 standards and can measure and record partial discharge (PD) and AC test voltage. DC voltage PD measurement is an optional feature of the standard instrument.

Product Parameter (specification)

Partial discharge measurement system

Number of partial discharge measurement channels	4- channel (multiple units can be connected) 16 channels)
Input impedance	50Ω
Analog filter ( -6 dB )	satisfy IEC60270 , GB/T7354-2018 standard
	Lower limit frequency fL : 10kHz 20kHz 40kHz 60kHz 80kHz optional
	Upper frequency limit fU : 100kHz , 200kHz , 300kHz , 400kHz , 500kHz 1 MHz Optional
Detection sensitivity	<1pC(CA =10nF/CK=1nF)
Detection sensitivity	<0.1pC(CA =1nF/CK=1nF)
Sampling accuracy	14 bit

Sampling rate	80MHz
Gain adjustment range	60dB 40dB 20dB 0dB , -20dB , -40dB Automatic or manual Adjust
Testable capacitance range	6pF~ 250 μF
linearity error	< ± 3%

Voltage measurement system

Number of voltage measurement channels	4 channels (multiple units can be connected) 16 channels)
Voltage input range	5~230VAC (RMS)
linearity error	< ± 3%
Frequency range	10~450Hz
Synchronization method	Automatic switching between power supply synchronization and voltage input synchronization
Synchronization accuracy	<1°

Interface

Partial discharge input	4 × BNC
Voltage input	4 ×Airplane plug
Ethernet / LAN	1 × RJ-45

PC Require

operating system	Windows 7/ Windows 10 64 -bit operating system
processor	Intel CORE i5 and above
Memory	8G and above
harddisk	128G and above
Network interface	10/100/1000 Mbps

Physical and environmental regulations

power supply	176~264 VAC 50/60Hz
Power fuse	250V T 5A
Operating temperature	-10°C to 50°C
Storage temperature	-40°C ~60°C
relative humidity	5%~95% No condensation

Dimensions (width × depth ×

high)

445mm × 355mm × 88mm

weight

11.7kg

Product feature and application

Multi-channel, high precision
4 channels, expandable to 16 channels; 80 MHz sampling rate / 14-bit resolution; partial discharge detection sensitivity < 0.1 pC
Wide-Range Adjustable Adaptability
Filter range: 10 kHz–1 MHz; 60 dB adjustable gain; measurable capacitance: 6 pF–250 μF; compatible with various types of high-voltage equipment
Stable and Compliant Adaptability
Wide operating temperature range: –10°C to 50°C; compliant with IEC 60270 and GB/T 7354-2018 standards; suitable for complex on-site operating conditions

Prodection details

Equipment Testing

Partial discharge quantification testing for high-voltage electrical equipment, including transformers, current transformers, cables, bushings, capacitors, surge arresters, and switches

Testing Procedures

Suitable for type testing, factory testing, and acceptance testing of high-voltage products, as well as both laboratory testing and on-site measurements
